FEATURES
-all steel internal components, without plastic parts,to ensure maximum resistance to attack
-electromagnet (activator) enclosed in a sturdy brass cover plate
| ■ Case: |
2 mm thick steel |
| ■ Frame: |
6 mm thick steel,Attack-proof steel rebated on top and bottom sides. The frame forms a one-piece body with the case |
| ■ Door: |
6 mm thick steel, Minimum space between door and frame to prevent insertion of burglary tools. |
| ■ Deadbolts: |
horizontal nickel-plated steel, with guides Ø 15 mm. ( Horiz. :3 ) |
| ■ Electronic board: |
protected against break-in attempts by high voltage electric shocks and against incorrectly inserted batteries |
| ■ Non-volatile Memory: |
stored codes and data are not erased if the batteries are removed. |
| ■ Combination: |
accepts codes from 3 to 8 digits (100 million possible combinations). |
| ■ Electronic block-out: |
after 5 consecutive error codes (for 15 minutes). |
|
Exterior Size H x W x D (mm) : 160 x 250 x 225
Interior Size H x W x D (mm) : 153 x 246 x 210
Weight (KG) : 6.5
|
"MINI" Electronic safe
Model: 4292
|
| |
|
| |
|
| |
FEATURES
-all steel internal components, without plastic parts,to ensure maximum resistance to attack
-electromagnet (activator) enclosed in a sturdy brass cover plate
| ■ Case: |
3 mm thick steel (for free standing version) |
| ■ Fins: |
steel on all rear sides ("L" shaped folded fins on both horizontal sides) of the case, to increase resistance to attack. |
| ■ Frame: |
10 mm thick steel |
| ■ Door: |
8 mm thick steel, banded on the hinge side for better pull-resistance. |
| ■ Deadbolts: |
horizontal rotating resistant to attack and vertical nickel-plated steel Ø 20 mm. ( Horiz. :3 Vert. :2) |
| ■ Electronic board: |
protected against break-in attempts by high voltage electric shocks and against incorrectly inserted batteries |
| ■ Non-volatile Memory: |
stored codes and data are not erased if the batteries are removed. |
| ■ Combination: |
accepts codes from 3 to 8 digits (100 million possible combinations). |
| ■ Electronic block-out: |
after 5 consecutive error codes (for 15 minutes). |
|
Exterior Size H x W x D (mm) : 290 x 410 x 350
Interior Size H x W x D (mm) : 280 x 404 x 300
Weight (KG) : 27.8
|
"PRIVACY" ELECTRONIC SAFES
Model: 1.4393
|
| |
|
| |
FEATURES
-all steel internal components, without plastic parts,to ensure maximum resistance to attack
-electromagnet (activator) enclosed in a sturdy brass cover plate
| ■ Case: |
3 mm thick steel |
| ■ Fins: |
steel on all rear sides ("L" shaped folded fins on both horizontal sides) of the case, to increase resistance to attack. |
| ■ Frame: |
10 mm thick steel |
| ■ Door: |
10 mm thick steel, banded on the hinge side for better pull-resistance. |
| ■ Deadbolts: |
horizontal rotating resistant to attack and vertical nickel-plated steel Ø 20 mm. ( Horiz. :3 Vert. :2) |
| ■ Electronic board: |
protected against break-in attempts by high voltage electric shocks and against incorrectly inserted batteries |
| ■ Non-volatile Memory: |
stored codes and data are not erased if the batteries are removed. |
| ■ Combination: |
accepts codes from 3 to 8 digits (100 million possible combinations). |
| ■ Electronic block-out: |
after 5 consecutive error codes (for 15 minutes). |
|
Exterior Size H x W x D (mm) : 555 x 350 x 460
Interior Size H x W x D (mm) : 545 x 344 x 410
Weight (KG) : 46.2
|
"PRIVACY" ELECTRONIC SAFES
Model: 1.4398
|
| |
|
| |
FEATURES
-all steel internal components, without plastic parts,to ensure maximum resistance to attack
-electromagnet (activator) enclosed in a sturdy brass cover plate
| ■ Case: |
3 mm thick steel |
| ■ Fins: |
steel on all rear sides ("L" shaped folded fins on both horizontal sides) of the case, to increase resistance to attack. |
| ■ Frame: |
10 mm thick steel |
| ■ Door: |
10 mm thick steel, banded on the hinge side for better pull-resistance. |
| ■ Deadbolts: |
horizontal rotating resistant to attack and vertical nickel-plated steel Ø 20 mm. ( Horiz. :3 Vert. :2) |
| ■ Electronic board: |
protected against break-in attempts by high voltage electric shocks and against incorrectly inserted batteries |
| ■ Non-volatile Memory: |
stored codes and data are not erased if the batteries are removed. |
| ■ Combination: |
accepts codes from 3 to 8 digits (100 million possible combinations). |
| ■ Electronic block-out: |
after 5 consecutive error codes (for 15 minutes). |
|
Exterior Size H x W x D (mm) : 790 x 440 x 500
Interior Size H x W x D (mm) : 780 x 434 x 450
Weight (KG) : 76.0
|
"PRIVACY" ELECTRONIC SAFES
Model: 1.4396
|
| |
|
| |
FEATURES
-all steel internal components, without plastic parts,to ensure maximum resistance to attack
-electromagnet (activator) enclosed in a sturdy brass cover plate
| ■ Case: |
3 mm thick steel (for free standing version) |
| ■ Frame: |
10 mm thick steel. Specially rebated steel around the entire frame perimeter to increase resistance to attack. |
| ■ Door: |
10 mm thick steel, banded on the hinge side for better pull-resistance. Minimum space between door and frame to prevent insertion of burglary tools. |
| ■ Deadbolts: |
horizontal and vertical rotating, nickel-plated stee Ø 22 mm. ( Horiz. 2 Vert. :2) |
| ■ Key: |
supplied with 2 nickel-plated brass double bit keys with non-slip ABS covered head |
| ■ Mechanism: |
- keys removable only when the door is closed;
- 6 gorge steel lock with different, independent depth. Numerous keying possibilities. |
|
Exterior Size H x W x D (mm) : 300 x 420 x 350
Interior Size H x W x D (mm) : 290 x 414 x 284
Weight (KG) : 29.7
|
"PRIVACY" mechanical safes
Model: 1.4314.35
|
| |
|
| |
FEATURES
-All steel construction without plastic parts. Reinforced door, 6 mm. thick
-Scratch proof painting and shock-proof internal carpet
| ■ Suitable dimensions for most up to date laptops |
| ■ Motorized opening and closing, with closing code technology. Door opening is automatic |
| ■ Controlled door opening: after the opening confirmation is given, the door automatically opens with a spread of 2 cm |
| ■ Low consumption, protected electronics |
| ■ High brightness alphanumerical display |
| ■ADA compliant keypad with Braille marking and acoustic confirmation |
| ■ Flat battery audio-visual warning and battery charge % level on display |
| ■ Hierarchical Master Codes System (up to 6 levels) with Directional Passepartout |
| ■ Resident Codes (Codes remain in memory even if batteries are failed) |
| ■ When electronic keys are supplied (on request) Master Codes are stored in the key and not in the safe memory |
| ■ Audit trail of the last 150 operations, protected by password with print option |
| ■ Microswitch controlling the actual door closing maximum reliability of audit |
| ■ Electronic input block after 7 consecutive wrong attempts |
| ■ Mechanical emergency opening |
|
Exterior Size H x W x D (mm) : 200 x 410 x 400
Interior Size H x W x D (mm) : 193 x 406 x 350
Weight (KG) : 15
Volume (Lt.) : 27,4
|
"PRIVACY" ELECTRONIC SAFES
Model: 1.4393
|
| |
|
| |
FEATURES
| ■ Case: |
1.5 mm thick steel in compliance with UNI EN 10130 standard. Rounded edges to avoid abrasion. 4 through holes, Ø 9 mm, on the rear for fixing to the wall with expansion plugs. |
| ■ Door: |
2 mm thick steel, rebated on three sides, replaceable, protected on the hinge side for pull-resistance. |
| ■ Deadbolts: |
painted steel: 2 horizontal Ø 14 mm and 2 vertical Ø 12 mm. |
| ■ Key: |
supplied with 2 nickel-plated brass double bit keys with non-slip ABS covered head |
| ■ Mechanism: |
- electromagnet (activator) protected by a steel plate;
- ADA compatible keypad with Braille markings and acoustic confirmation
-
4 adjustable-height shelves with 15 Kg max. capacity each, suitable dimensions for laptops and printouts; |
| ■ Electronic board: |
protected against incorrectly inserted batteries |
| ■ Non-volatile memory: |
stored codes and data are not erased if the batteries are removed. |
| ■ Combination lock: |
accepts codes from 3 to 8 digits (100 million possible combinations) |
|
Exterior Size H x W x D (mm) : 1500 x 536 x 380
Interior Size H x W x D (mm) : 1310 x 533 x 327
Weight (KG) : 71.5
Volume (m3) : 0.31
|
With electronic combination lock - file cabinet
Model: 4443.TR
|
| |
|
|
|
|
