MODEL 74 - KOMBIFRANK |
BASIC CONSTRUCTION |
|
Laser-cut steel door, 8 mm (total thickness 42 mm). Full light-opening, full-height hinge. Two chromium-plated bolts, Ø 20 mm, mounted on double support. U-shaped, anti-smashing rabbets (4mm) . Strong robotized weldings. Single-walls body , 3 mm thickness. Fixing holes (Ø 12 mm) at rear and base. Displaceable shelves. |
CLOSING SYS |
|
2-coaxial- wheels combination lock, antimanipulation. 2 Numers; 12.000 possible variations; change by key. The combination can be set at zero if door is open. |
|
SIZE |
|
|
Model 74 |
|
|
|
|
|
MODEL 68/8 - KEYCOMBI DEPOSAFE |
REINFORCED CONTRUCTION
|
|
Laser-cut steel door, 8 mm (total thickness 55mm) Full-light opening, full-height hinge. U-shaped, anti-smashing rabbets (4 mm). Chromium-plated, independent, turning bolts, Ø25 mm, mounted on double support 4+4 mm. Armoured locks protected by a reinforcement-plate in manganese-steel material. Strong robotized weldings. Internal deep-drawn cover, it can be dismantled just when lock is open. 5 mm single-wall body. Fixing holes (Ø 12 mm) at rear and base. |
CLOSING SYS |
|
Antimanipulation lock, 8 effective levers, 2 turns. Bicyphered keys (48.017.788 effective variations). Device certified according to European Norm EN 1300 Class B.
LOCK CERTIFICATION (DEVICE L2) |
|
BLOCKING SYSTEM |
|
3-coaxial- wheels combination lock, antimanipulation. 3 Numbers; 1.440.000 possible variations; change by key. The combination can be set at zero if door is open. Devise certified according to the European Norm EN 1300 Class B.
LOCK CERTIFICATION (DEVICE C1) |
|
SIZE |
|
|
Model 68/8 |
|
|
|
|
|
MODEL 67/5 - REMEDY |
REINFORCED CONTRUCTION
|
|
Laser-cut steel door, 8 mm (total thickness 55mm) Full-light opening, full-height hinge. U-shaped, anti-smashing rabbets (4 mm). Chromium-plated, independent, turning bolts, Ø25 mm, mounted on double support 4+4 mm. Armoured locks protected by a reinforcement-plate in manganese-steel material. Strong robotized weldings. Internal deep-drawn cover, it can be dismantled just when lock is open. 5 mm single-wall body. Fixing holes (Ø 12 mm) at rear and base. |
CLOSING SYS |
|
Digital electronic combination, system CE tested. 111.111.000 effective variations, motorized. Alimentation: 6V battery (4 x 1,5V—LR6 AA), external supply possibility (9V battery LR61). Low-Power processor (low consumption technology). Manipulation Test, anti-manipulation block.
Basic combination : 00.00.00 (6 zeros) On request : Emergency-Code Version, like for Hotel use (of standard production on Mod.78) or programmable Time-Delay-Version. |
|
EMERGENCY-KEY |
|
Antimanipulation lock, 8 effective levers, 2 turns. Bicyphered keys (48.017.788 effective variations). Device certified according to European Norm EN 1300 Class B.
LOCK CERTIFICATION (DEVICE L2) |
|
SIZE |
|
|
Model 67/5 |
|
|
|
|
|
|
|
|
|
|
|
