MADE IN ITALY

意大利製造

MODEL 74 - KOMBIFRANK


BASIC CONSTRUCTION

Laser-cut steel door, 8 mm (total thickness 42 mm). Full light-opening, full-height hinge. Two chromium-plated bolts, Ø 20 mm, mounted on double support. U-shaped, anti-smashing rabbets (4mm) . Strong robotized weldings. Single-walls body , 3 mm thickness. Fixing holes (Ø 12 mm) at rear and base. Displaceable shelves.


CLOSING SYS


2-coaxial- wheels combination lock, antimanipulation. 2 Numers; 12.000 possible variations; change by key. The combination can be set at zero if door is open.

SIZE
Model 74





MODEL 68/8 - KEYCOMBI DEPOSAFE


REINFORCED CONTRUCTION


Laser-cut steel door, 8 mm (total thickness 55mm) Full-light opening, full-height hinge. U-shaped, anti-smashing rabbets (4 mm). Chromium-plated, independent, turning bolts, Ø25 mm, mounted on double support 4+4 mm. Armoured locks protected by a reinforcement-plate in manganese-steel material. Strong robotized weldings. Internal deep-drawn cover, it can be dismantled just when lock is open. 5 mm single-wall body. Fixing holes (Ø 12 mm) at rear and base.


CLOSING SYS



Antimanipulation lock, 8 effective levers, 2 turns. Bicyphered keys (48.017.788 effective variations). Device certified according to European Norm EN 1300 Class B.
LOCK CERTIFICATION (DEVICE L2)



BLOCKING SYSTEM


3-coaxial- wheels combination lock, antimanipulation. 3 Numbers; 1.440.000 possible variations; change by key. The combination can be set at zero if door is open. Devise certified according to the European Norm EN 1300 Class B.
LOCK CERTIFICATION (DEVICE C1)



SIZE
Model 68/8





MODEL 67/5 - REMEDY


REINFORCED CONTRUCTION


Laser-cut steel door, 8 mm (total thickness 55mm) Full-light opening, full-height hinge. U-shaped, anti-smashing rabbets (4 mm). Chromium-plated, independent, turning bolts, Ø25 mm, mounted on double support 4+4 mm. Armoured locks protected by a reinforcement-plate in manganese-steel material. Strong robotized weldings. Internal deep-drawn cover, it can be dismantled just when lock is open. 5 mm single-wall body. Fixing holes (Ø 12 mm) at rear and base.


CLOSING SYS



Digital electronic combination, system CE tested. 111.111.000 effective variations, motorized. Alimentation: 6V battery (4 x 1,5V—LR6 AA), external supply possibility (9V battery LR61). Low-Power processor (low consumption technology). Manipulation Test, anti-manipulation block.
Basic combination : 00.00.00 (6 zeros) On request : Emergency-Code Version, like for Hotel use (of standard production on Mod.78) or programmable Time-Delay-Version.



EMERGENCY-KEY


Antimanipulation lock, 8 effective levers, 2 turns. Bicyphered keys (48.017.788 effective variations). Device certified according to European Norm EN 1300 Class B.
LOCK CERTIFICATION (DEVICE L2)



SIZE
Model 67/5
